Three Phase Motor
Three-phase motors (also annotated numerically as 3-phase motors) are widely used in industry and have become the workhorse of many mechanical and electromechanical systems because of their relative simplicity, proven reliability, and long service life. Three-phase motors are one example of a type of induction motor, also known as an asynchronous motor, that operates using the principals of electromagnetic induction. While there are also single-phase induction motors available, those types of induction motors are used less frequently in industrial applications but are widely used in domestic applications such as in vacuum cleaners, refrigerator compressors, and air conditioners, owing to the use of single-phase AC power in homes and offices.
Features
- Motor type : AC three-phase squirrel cage induction motor
- Degree of protection : IP 55, Enclosure : TEFC, Duty / Rating : S1 / Continuous, Ambient temperature : +50°C.
- Voltage ± variation : 415 V ± 10% • Frequency ± variation : 50 Hz ± 5%.
- Combined variation : 10% (Absolute sum).
- Relative humidity : Up to 100%.
- Connection : Up to 2.2 kW-Star connection with 3 leads & above 2.2 kW-Delta connection with 6 leads.
- Direction of rotation : Anticlockwise or clockwise as seen from the Driver end side.
- Insulation class : Class ‘F’ and temperature rise limited to class ‘B’.
- Cooling method : IC411 / Shaft mounted fan.
Technical Specification
- Frame : 63 to 160 L
- KW : 0.18 to 15
- HP : 0.25 to 20
- RPM : 2900,1500,1000,750
- I. Class : B & F
- Duty : S1,S2,S3,S4
- Enclosure : TEFC,TESC
- Protection : IP44,IP55,IP54
